testo 557s AC Manifold Gauge Set – AC Recharge Kit with 2 x 115i Pipe Clamp Thermometer, 1 x 552i Micron Gauge & 4-Way Valve - Set with Bluetooth and App-Connection

testo 557s testo gauges hvac - Remote and accurate measurements of pressure, vacuum and pipe temperatureThe testo 557s ac recovery machine is the life-saving tool for every HVAC technician. It replaces a number of tools in the A/C and refrigeration industry and measures pressure, temperature and superheating as well as subcooling fast and reliably. Thanks to its smart Bluetooth integration, data can be measured, stored and evaluated reliably and efficiently from afar, thus saving precious time and resources. Technical Data 557s: Temperature measuring range: -58° to +302°F / - 50° to +150°C Temperature measurement accuracy: +-0.9 °F / +-0.5 °C Temperature measurement resolution: 32.2 °F / 0.1 °C Pressure measuring range: -15 to 870 psi / -1 to 60 bar Pressure measurement accuracy: +-0.5 % of full-scale value Pressure overload relay: 943 psi / 65 bar Vacuum measuring range: 0 to 20000 micron Battery life: 50 hours Battery type: 2 x AA Measuring range: 0.5 sec Weight: 18 oz. / 500 g Dimensions: 6 x 4 x 2 in. / 160 x 110 x 50 mm Hoses: Length: 5 ft. / 1,52 m System requirements: requires iOS 11 or higher; requires Android 6 or higher; requires mobile end device with Bluetooth 4.0 Scope of delivery: 1 x Testo 557s Manifold with 2 x 115i Pipe Clamp thermometer, 1 x 552i Micron Gauge (4 x hoses with optional Kit) Transport case, Instruction manuals

• Versatile; The vacuum gauge replaces multiple HVAC gauges and was developed to deliver extremely precise temperature, pressure, and vacuum measurements on refrigerant systems and heat pumps
• User-friendly; With its intuitive menu, 4-way valve block and automated probe connection, the digital manifold gauge provides convenient pressure measurement in areas that are difficult to access
• Wide range; The micron gauge offers reliable temperature measuring range of -58° to 302 °F / -50 to +150 °C, pressure measuring range of -15 to 870 psi / -1 to 60 bar, and vacuum measuring range of 0 to 20000 micron
• Precise; Thanks to the sensitive sensors, the vacuum gauge provides temperature accuracy of +-0.9 °F / +-0.5 °C, pressure measurement accuracy +-0.5 % of full-scale value, and vacuum measurement accuracy +- (10 micron + 10 % of mv) (100 to 1000 micron)
• Smart App; Take advantage of clearly visualized documentation from a smartphone or tablet. Remotely operate your refrigerant gauge, execute service and maintenance tasks, and send results directly from the job site
